Pipe-based Wire Wrap Screen - Carbon Steel Base Pipe, 304 Stainless Steel Wrap, LTC Connections
Product Overview
Oasis Pipe-based Wire Wrap Screen is engineered to deliver exceptional performance in demanding well completion and sand control applications. Constructed with a robust carbon steel base pipe and a precision-wound 304 stainless steel screen jacket, this product combines superior mechanical strength with reliable filtration efficiency. Equipped with standard LTC (Long Thread and Coupling) connections, it ensures easy installation and secure integration into your well system. Available in lengths up to 12 meters, our screens are designed to meet the rigorous requirements of deep water wells, oil wells, gas wells, and vertical well completions.
Key Features & Advantages
- High Collapse Resistance: Heavy-duty carbon steel base pipe (available in J55, K55, N80, L80, and P110 grades) provides excellent structural integrity to withstand high downhole pressures in deep well applications
- Precision Filtration: Continuous slot design created by 304 stainless steel wire wrapping delivers consistent and accurate sand control, preventing formation sand production while maximizing flow rates
- Corrosion Resistance: 304 stainless steel screen jacket offers superior corrosion resistance compared to carbon steel alternatives, extending service life in various downhole environments
- Reliable LTC Connections: Standard Long Thread and Coupling connections ensure quick, secure, and leak-proof installation, compatible with most industry-standard well completion equipment
- Optimized Flow Area: Uniformly spaced perforations (available in 9mm, 11mm, 16mm, and 19mm diameters) on the base pipe maximize fluid flow while maintaining structural strength
- Customizable Design: Available in a wide range of standard sizes to fit different well casing dimensions
-
Technical Specifications
More Details
Why Choose Oasis Pipe-based Wire Wrap Screen?
We manufacture screens using advanced production techniques and strict quality control processes to ensure consistent performance and reliability. Each screen undergoes rigorous testing to verify dimensional accuracy, mechanical strength, and filtration efficiency. Whether you're operating in shallow or deep wells, our pipe-based wire wrap screens provide the durability and performance you need to maximize well productivity and minimize downtime.
Contact us today to discuss your specific requirements and receive a customized solution for your well completion project.
<img alt="" data-cke-saved-src=" <div style=" src=" <div style=" font-style:="" normal;="" font-variant:="" font-size-adjust:="" none;="" font-language-override:="" font-kerning:="" auto;="" font-optical-sizing:="" font-feature-settings:="" font-variation-settings:="" font-stretch:="" font-family:="" ui-sans-serif,="" system-ui,="" sans-serif,="" "apple="" color="" emoji",="" "segoe="" ui="" symbol",="" "noto="" emoji";="" font-size:="" 16px;="" line-height:="" 24px;="" flex:="" 0="" 1="" flex-direction:="" row;="" justify-content:="" align-items:="" padding:="" 0px;="" margin:="" background:="" none="" 0%="" auto="" repeat="" scroll="" padding-box="" border-box="" rgba(0,="" 0,="" 0);"="">
Related Products
|
|
Premium 304 Stainless Steel Insect Screen Mesh - Durable Rust Proof Fine Mesh for Window Door Ventilation Images
|
